Automatic Eight-Head Pick and Place Type Screw Cap Sealing with Eight-Head Measuring Cup Pressing Machine

Automatic Eight-Head Pick and Place Type Screw Cap Sealing with Eight-Head Measuring Cup Pressing Machine preset with anyone bottle and cap/ cup parts.

Automatic 8-Head Pick and Place Screw Cap Sealing with Measuring Cup Pressing Machine

Automatic 8-Head Pick and Place Screw Cap Sealing with Measuring Cup Pressing Machine

The Automatic 8-Head Pick and Place Screw Cap Sealing with Eight-Head Measuring Cup Pressing Machine from USA Pack Machines LLC represents a cutting-edge solution for high-speed, precise, and fully automated capping and cup-pressing operations. Designed for versatility, this advanced machine can be preset to handle a wide variety of bottles, caps, and measuring cup parts, making it ideal for pharmaceutical, food, beverage, cosmetic, and chemical industries.

Built with a robust stainless steel structure, the machine integrates eight synchronized screw capping heads and eight measuring cup pressing units, ensuring that each bottle is sealed and capped consistently with high accuracy. The pick-andplace mechanism precisely positions the caps and cups onto bottles, while the multi-head system enables simultaneous processing, significantly increasing throughput and production efficiency.

During operation, bottles are guided through the product transmission belt with an adjustable guide. As each bottle reaches the capping station, the pick-and-place heads place the caps accurately, and the measuring cup pressing heads secure the cups to the bottles. The height adjustment system ensures seamless adaptation to bottles of varying sizes, while the optional safety acrylic cover provides operator protection without obstructing visibility or access.

The machine’s integrated automation reduces manual handling, minimizes errors, and guarantees consistent sealing quality. Furthermore, its synchronized design allows easy presetting for different bottle, cap, or cup types, providing exceptional flexibility for multiple production lines.

Manufacturers benefit from enhanced productivity, reduced downtime, and optimized operational efficiency. The machine’s user-friendly interface and reliable electrical and pneumatic components allow smooth operation and minimal maintenance.

By choosing USA Pack Machines LLC, businesses gain a reliable partner that delivers precision-engineered packaging solutions. The Automatic Eight-Head Pick and Place Screw Cap Sealing with Measuring Cup Pressing Machine ensures rapid, accurate, and consistent sealing and pressing for modern production requirements, helping manufacturers maintain high standards of quality and efficiency.

Category:
Inquiry Now
# Model Output Speed
1 UPML–PPSCSWMCP-8 120 BPM
  • The machine is manufactured or developed per GMP standards.
  • The structure is made of MS cladded with SS 304.
  • Rigid vibration-free construction for trouble-free performance.
  • SS elegantly matt-finished body.
  • MS powder coated or electroless nickel plating of all exposed parts to ensure long life and resistance against corrosion.
  • Low noise level, low power consumption.
  • Single drive synchronized complete operation.
  • Minimum change over time.
  • Minimum setting time.
  • Very little mechanical adjustment is required due to the special design.
  • User-friendly and very little maintenance required.
  • Equipped with PLC – HMI interface.
Model HMPL–PPSCSWMCP-8
Product MOC & Type Round Glass Bottle
Product Volume 60 ML, 115 ML, 180 ML & 500 ML
Total Nos. of product 4 NOS
Type of Cap Plastic Screw Cap with ring
Capping Head Type Plastic Screw
Cap Size As per sample product
Type of Cup Plastic
Cup Size As per sample product
Maximum Height of Product As per sample product
Minimum Height of Product As per sample product
Maximum Diameter/ Width of Product As per sample product
Maximum Diameter/ Width of Product As per sample product
Model HMPL–PPSCSWMCP-8
Product MOC Round Glass Bottle
Product Size 60 ML, 115 ML, 180 ML & 500 ML
Cap Type Plastic Screw Cap with Ring
CUP MOC Plastic
Cap Feeding System Vibratory Bowl with Suitable Cap Chute
Nos. of Capping Head 8 NOS
Cap Head Type Plastic Screw Cap
Output Speed 120 Bottles/Minute (Speed depending on bottle & cap size & also depending upon operator efficiency/feeding arrangement)
Nos. of Cup Pressing Head 8 NOS
Power Supply Three Phase / 415 V AC / 50 Hz
Working Height 875 + 50 mm Adjustable
Direction Left to Right
