Automatic Shrink Sleeve Label Applicator Machine
Automatic Shrink Sleeve Label Applicator Machine
The Automatic Shrink Sleeve Label Applicator Machine from USA Pack Machines LLC is engineered for precision, speed, and durability in modern packaging operations. This advanced system includes a robust main structure, product transmission belt with adjustable guides, an in-feed screw, sleeve former (mandrel), and a rotary cutter for accurate sleeve cutting. For safety and reliability, it features an acrylic protective cover, while the integrated shrink tunnel with a cooling fan ensures smooth and secure label application. Powered by motors, sensors, AC drives, PLC, and HMI controls, this machine delivers user-friendly operation with high performance.
As a leading manufacturer of shrink sleeve technology, USA Pack Machines LLC offers innovative sleeving solutions tailored to the needs of diverse industries. By supplying high-quality machines designed for efficiency, the company supports businesses in pharmaceuticals, beverages, dairy, and cosmetics. With its superior accuracy, the applicator ensures flawless labeling on every container surface. Furthermore, its long service life and low-maintenance design reduce overall production costs while enhancing output efficiency.
Shrink Sleeve Applicator
The Shrink Sleeve Applicator by USA Pack Machines LLC provides unmatched versatility, accommodating glass, HDPE, and plastic bottles. It supports container diameters ranging from 30 mm to 120 mm, sleeve lengths between 30 mm and 100 mm, and sleeve widths of 40 mm to 170 mm. Delivering speeds of 60 to 200 bottles per minute (depending on sleeve cut length), this machine is ideal for high-volume production lines that demand accuracy and consistency.
Electrical Heater Operated Shrink Tunnel
The Electrical Heater Operated Shrink Tunnel ensures uniform sleeve shrinking through advanced heating elements that distribute heat evenly. This technology achieves smooth, wrinkle-free sleeves, enhancing both aesthetics and protection. Designed for integration with production lines, it maximizes efficiency while offering durability and easy operation.
Steam Operated Shrink Tunnel
The Steam Shrink Tunnel provides a powerful yet energy-efficient method of applying shrink sleeves. By using steam, it ensures flawless, wrinkle-free finishes on containers of all shapes and sizes. Its advanced design enables seamless integration and precise heat control, making it ideal for diverse applications.
Steam Generator
The Steam Generator delivers consistent and reliable steam output for shrink sleeve tunnels and other industrial applications. With a rugged build and advanced safety features, it guarantees dependable performance. Easy to monitor and adjust, it ensures smooth operation, boosting both productivity and packaging quality in demanding environments.
| # | Model | Output Speed |
| 1 | UPML-SSA | 60 to 200 Bottles/Minute (Speed depends on cut length) |
- The Shrink Sleeve Applicator machine is manufactured or developed accordance with GMP standards.
- The structure of Shrink sleeve applicator and conveyor are made of SS 304 and internal parts will be MS powder coated / hard chrome plated.
- Rigid vibration free construction for trouble free performance.
- The SS 304 slat conveyor for proper product conveying (For the processes of sleeve inserting and Automatic sleeve shrinking).
- In-feed screw for the positive feeding of bottle.
- The movement of shaft is controlled by servo motor to ensure intermittent flow of the sleeve roll during its travel along the dancing rollers.
- Specially designed cutter device with PLC controlled for cutting of sleeve.
- Total operation of the machine like speed of conveyor, speed of feeder, length of sleeve, cutting speed etc. are controlled by PLC.
- Easy to operate PLC by mean of feather touch HMI
- User-friendly and very less maintenance required because of less usage of mechanical components.
- The construction of machine’s electrical panel is in line with the IP 55 standard.
- In case roll gets over, there is alarm notification (buzzer) for indicating the same
- Web guide control to ensure that there is no lateral movement of sleeve laminate
- Gaskets, seals and O-rings are constructed of food grade/ non-toxic polymeric materials only
- All welds are ground finished
- Provision of Photocell sensor to read the eye mark- eye mark distance on the sleeve roll which generates the length of the sleeve suitable as per the bottle size (If printed sleeves are used).
- Separate Stepper Motors for controlling the movement of rotary brushes to ensure that sleeve is properly settled on bottle
- Sensor to indicate the presence of bottle, immediately after which the sleeve should be dispensed on bottle. If there is NO BOTTLE NO SLEEVE will be dispensed
- Unique compact tunnel with minimal power consumption
- The tunnel comprised of pre and post heat shrink zone to shrink the sleeve on bottle
- The heaters are installed at the side of the tunnel to ensure that there is uniform distribution of heat on the sleeve
- Overhead convection fan for precise cooling at output
- Digital temperature controller to ensure that uniform temperature is maintained at the time of shrinking
- The change over time from one SKU to other will take approximately 30 to 45 min
- Cleaning is done manually and all those sections which have to be cleaned are easily dismantled
- Design of equipment with enhanced cleaning feasibility by providing minimum sharp corners, minimum crevices & smooth finished welds joints
- Sleeve feeding controlled by PLC for the accurate feeding of sleeve.
- Specially designed rotary cutter device with PLC controlled for cutting of sleeve.
- Warning stickers on all external & moving surfaces
- Appropriate closure of all the rotation parts
- Emergency stop function on accessible area
- Noise level below than 75 DB
- Power restart will not be automatic and human intervention must be required
- After regain of power the equipment shall start from the step it stopped
- Total operation of the machine like speed of conveyor, speed of feeder, length of sleeve, cutting speed etc. are controlled by PLC.
- Easy to operate PLC by mean of touch screen HMI.
- User friendly and very less maintenance required because of less usage of mechanical components
- Most reliable and proven components such as Festo/SMC make pneumatic and electric/electronic components such as Panasonic/Bonfiglioli/Motovario make AC motor, Delta make AC Drive, PLC & HMI, Sensor LEUZE/BANNER/SICK, MCB & relay “CE” certified.
| Bottle Sample | Glass/HDPE/Plastic Bottles |
| Bottle Size (Ø) | 30 mm Ø to 120 mm Ø |
| Sleeve Length | 30 mm to 100 mm |
| Sleeve Width | 40 mm to 170 mm |
| Sleeve Material | OPS & PVC with 40 to 50 micron & 55% shrink ratio |
| Output Speed | 60 to 200 Bottles/Minute (Speed depends on cut length) |
| Working Height | 850 ± 50 mm Adjustable |
| Power Consumption | 6.5 KW |
| Power Supply | 3 Phase + Neutral + Earthing / 440V AC / 50Hz |
| Net Weight | 550 Kg Approx. |
| Dimensions | 3050 mm (L) x 1200 mm (W) x 2000 mm (H) Approx. |
Shrink Sleeve Applicator
Shrink Sleeve Applicator designed for glass, HDPE, and plastic bottles, handling diameters of 30–120 mm with sleeve sizes from 30×40 mm to 100×170 mm. Delivers 60–200 bottles per minute, ensuring precision and reliability for high-speed packaging.
Electrical Heater Operated Shrink Tunnel
Electrical Heater Operated Shrink Tunnel designed for uniform sleeve application with precise heat distribution. Ensures smooth, tight fitting on various containers, integrates easily into production lines, and delivers reliable performance with consistent quality.
Steam-Operated Shrink Tunnel
Steam Operated Shrink Tunnel ensures efficient, uniform sleeve application with smooth, wrinkle-free results. Suitable for containers of various shapes and sizes, it offers energy efficiency, easy line integration, and reliable performance for high-quality packaging.
Steam Generator
Steam Generator designed to deliver consistent steam for shrink sleeve tunnels and other industrial applications. Built for efficiency, durability, and safety, it ensures precise temperature control, easy operation, and seamless integration into production lines.
