Pressure Leak Check Machine for IV Bottles

USA Pack Machines LLC offers a Pressure Leak Check Machine for 100 ml to 1000 ml IV/Infusion bottles, delivering a speed of 100–120 bottles per minute. Bottles are manually loaded, pressurized for testing, and automatically separated if a leak is detected.

Pressure Leak Check Machine for IV/Infusion Bottles

Pressure Leak Check Machine for IV/Infusion Bottles

USA Pack Machines LLC offers the Pressure Leak Check Machine, designed specifically for 100 ml to 1000 ml IV/Infusion Bottles, providing an efficient output speed of 100 to 120 bottles per minute. This machine ensures the integrity of filled bottles by accurately detecting leaks, making it an essential addition to pharmaceutical packaging lines.

How Does It Work?

The machine operates with precision and simplicity. Operators manually load IV bottles onto the stainless-steel conveyor belt, which guides them through the pressurization zone. Here, the bottles pass between an SS rod and a wheel, where uniform pressure is applied. If a bottle shows any leakage, the operator promptly separates it from the batch, ensuring that only leakfree bottles continue through the production process.

he machines also integrates seamlessly with visual inspection systems, sticker labelling machines, and packing conveyors, creating a smooth and efficient inline packaging operation. Its specialized stainless-steel conveyor with a hook system, rotary bottle forwarding assembly, Hylum wheel with rubber belt, spring-loaded pressure assembly, and drive unit work in perfect harmony to maintain precise testing conditions. Additionally, the adjustable stainless-steel slat chain and sturdy pipe frame provide durability and stability during continuous operations.

Why Choose USA Pack Machines LLC?

At USA Pack Machines LLC, we design machinery to combine reliability, precision, and user-friendly operation. Our engineering team develops customizable solutions to meet specific client requirements, ensuring machines deliver consistent results while optimizing production efficiency. By investing in our pressure leak check equipment, pharmaceutical companies can reduce defective products, minimize recalls, and maintain compliance with industry standards.

Moreover, we offer dedicated after-sales support, guiding clients through setup, calibration, and maintenance to ensure longterm machine performance. Our solutions cater to startups, SMEs, and large enterprises, adapting to different production capacities and packaging needs.

Categories: ,
Inquiry Now
# Model Output Speed
1 UPML-LC 200 to 220 Bottles/Minute @ 100 ml (Depending upon the operators)
  • The machine is manufactured or developed per GMP standards.
  • SS square pipe frame structure with doors of SS 304 sheet.
  • All moving parts of the machine are covered by SS safety guards.
  • All exposed parts of SS/electroless nickel plated.
  • Dual track SS chain conveying system to convey the product with easy adjustable side guide.
  • Drive motor & gear mechanism.
  • The star plate & rotary plate (partially) is covered with an acrylic cover.
  • Back side mirror for leak check of bottle bottom.
  • Pressure alignment level for different sizes.
  • Star plate to lift the bottle.
  • The star plate & Rotary plate is made from UHMW-nylon.
  • Adjustable pressure rod.
  • Collection tray at the bottom to collect liquid of leakage bottles.
  • Bottles are to be loaded manually to the conveyor.
  • The bottles move on the conveyor & at the end of the conveyor, bottles are lifted with the help of a star plate.
  • Through the star plate bottle moves on a rotary plate with a pressure rod where the operator can check leakage in the bottles with the mean of pressure.
  • The operators remove the leaked bottles manually.
  • After the process of leak testing the bottles are transferred for further operation.
Model UPML–LC
Bottle MOC & Shape PE Flat I. V. Bottles/ Intravenous Fluids Bottles / IV Fluid Bottles
Bottle Volume 100 ml to 1000 ml
Conveyor Belt Width 40 mm
Conveyor Belt SS Slat
Both Side Working Space 7”
Output Speed 200 to 220 Bottles/Minute @ 100 ml (Depending upon the operators)
Working Height 950 mm ± 50 mm Adjustable
Power Supply Three Phase / 415 V AC / 50 Hz
Net Weight Approx. 200 Kg
Dimensions Approx. 2200 mm L x 875 mm W x 1530 ± 50 mm H Approx.
