Automatic Tube Filling, Sealing and Coding Machine

The Automatic Tube Filling, Sealing and Coding Machine consist of a main structure, tube moving with a tube holding unit, safety acrylic enclosure (OPTIONAL)

Automatic Tube Filling, Sealing and Coding Machine

Automatic Tube Filling,Sealing, and Coding Machine

USA Pack Machines LLC introduces the Automatic Tube Filling, Sealing, and Coding Machine, designed to deliver high precision, speed, and efficiency for modern production lines. Built with a durable main structure and equipped with a tube holding and moving unit, this machine ensures smooth handling of tubes during every stage of the operation. For enhanced safety, manufacturers can also choose an optional acrylic enclosure.

To accommodate different product types, the system features a jacketed hopper with a stirrer (optional) for consistent product flow, filling nozzles for accurate dosing, and a hot air sealing unit for secure closures. The integrated coding unit allows batch and product details to be marked clearly, supporting traceability and compliance. Controlled via a PLC and HMI interface (optional), the system gives operators intuitive controls and flexibility to adapt to diverse production requirements.

This automatic system is a versatile solution for a wide range of applications. It is perfectly suited for packaging creams, ointments, lotions, gels, pastes, and emulsions, making it indispensable for pharmaceutical, cosmetic, personal care, and healthcare industries. Whether producing toothpaste, skincare creams, medicated ointments, or herbal gels, the machine ensures precise filling, reliable sealing, and professional finishing.

The Automatic Tube Filling, Sealing, and Coding Machine integrates seamlessly into existing production environments, making it ideal for high-output manufacturing. It supports different tube types, including laminated, aluminum, and plastic tubes, while maintaining consistent quality across all product formats. Its flexibility enables businesses to scale production without compromising accuracy or hygiene.

USA Pack Machines LLC also offers comprehensive support for turnkey projects, including cosmetic and pharmaceutical manufacturing plants, ointment and cream filling plants, toothpaste production lines, and specialized mixers for emulsification and homogenization. By combining advanced engineering with decades of expertise, the company delivers solutions that meet USFDA and EU-GMP standards, ensuring global market readiness.

Categories: ,
Inquiry Now
# Model Output Speed
1 UPML–TFS Up to 150 Tubes/Minute (Depending on viscosity of material, loading & fill capacity)
  • The machine is manufactured or developed accordance with GMP standards.
  • Structure is made of MS cladded with SS 304.
  • This machine is specially designed to fill, seal and code the Aluminum / LAMI / PVC Tubes.
  • It can be used to fill viscous as well as semi viscous materials in Aluminum / LAMI / PVC Tubes.
  • Machine preset with 20gms to 100gms Piston & Cylinder.
  • All the contact parts are made of SS 316 (GMP Model).
  • Tube holders are made of nylon for different diameter of tube.
  • Relay electrical control systems operating panel with START, STOP and INCH.
  • SENSOR BASE NO TUBE NO FILLS MECHANISM.
  • Specially designed hot air sealing unit to seal PVC tubes.
  • Motor with variable speed.
  • All moving parts are guarded / enclosed.
  • Coding Device with 10 letters for one side.
  • Hopper temperature thermocouple with digital display.
Model HMPL–TFS
Tube Diameter 12 mm Ø to 50 mm Ø (Standard)
Tube Length 45 mm to 200 mm
Filling Capacity 10gms to 250gms Aluminum / LAMI / PVC Tubes (With the help of required change parts)
Output Speed 20 to 150 Tubes/Minute (Depending on viscosity of material, loading & fill capacity)
Filling Accuracy ± 1% of Filling Volume
Power Supply Three Phase / 440 V AC / 50 Hz
Compressed Air 4 to 5 Bar 100 L/Minute (If have sticky material)
Hopper ** 500 mm Ø 600 H
Change Parts a) Tube Holder b) Nozzle c) Auto Loader
